1. ELECTRICAL FAST TRANSIENT BURST CALIBRATION AS PER    IEC 61000-4-4  FOR  Pulse Amplitude: ±0.25 kV to ±5.4 kV
2. COMBINATION   WAVE SURGE TEST AS PER IEC   61000-4-5  Voltage Amplitude: ±0.25 kV to ±20.0 kV
3. ELECTROSTATIC DISCHARGE GENERATOR -ESD AS PER IEC 61000-4-2  Current : ±2kV to ±30 kV  (Current and Output Voltage calibration)
4. POWER FREQUENCY MAGNETIC FIELD IMMUNITY  AS PER IEC 61000-4-8   Current (continuous and short duration, 1 to 3 s) : 1 A/m to 1000 A/m
5. IMPULSE MAGNETIC FIELD AS PER  IEC 61000-4-9 AS PER  Short circuit peak current : 100 A to 1000 A
6.  VOLTAGE DIPS AND INTERRUPTION AS PER  IEC 61000-4-11 & IEC 61000-4-29,
7.  RING WAVE GENERATOR AS PER IEC 61000-4-12 Open Circuit Voltage : 250 V to 6 kV
8. ESD Target Low freq. Transfer Impedance, DC resistance AS PER IEC 61000-4-2   :0.02Ω-0.2Ω
9. RF POWER AMPLIFIER : (Gain :  5dB to 65 dB , Harmonics (9kHz to 15GHz) and Power Measurement : +15dBm to -60dBm )    9kHz to 6 GHz : All MW solid state RF amplifiers upto +70dBm,
10.  LISN  AS PER  CISPR 16-1-2, MIL-STD-461G, IEC 61000-4-6, ANSI C63.5, :9 kHz to 1000 MHz
11.  Current Probe    Transfer Impedance: 20Hz-1000MHz
12.  Antenna 2m loop Antenna, and Monopole/Rod Antenna AS PER  CISPR 16-1-4 : 9kHz-60 MHz
13.  Frequency Measure :  9kHz to 15 GHz
14.  RF Parameters : Attenuation,  Voltage Division Factor / Coupling Decoupling Factor/Isolation, Insertion loss :  9 kHz to 15GHz
15.  Amplitude Modulation :   9kHz to 15GHz
16.  Transfer Impedance –RF Current Clamp :  20Hz to 1000 MHz
17. SOURCE : Frequency (20 Hz-3.2 GHz), Power Measurement  ( +15dBm to -60dBm (9 kHz-6 GHz) )
18. Damped Oscillatory As per IEC 61000-4-18
19. PD Detector & PD Calibrator As per IS/IEC 60270
20. Monopole/ ROD Antenna @9 kHz -60 MHz as per MIL-461G
21. DC Current:10 μA to 10A
22. DC Voltage: 1 mV to 1000V
23. AC Current: 10uA to 1000A,
24. AC  Voltage:  1mV to 1300V,
25. PF: 0.01 (LAG/LEAD) to UPF
26.  Harmonics : 2nd order to 40th order
27. Phase Angle :(-)180 ° to 180 °
28. Capacitance: 1 nF to 100 μF
29. Resistance: 0.01 ohm to 100 Mohm
30. Power Meter, Energy Meter (ENERGY & POWER)

            ACTIVE(10 mWh to 115.2 kWh) ,

            REACTIVE (10 mVARh to 115.2 kVARh)

             APPARENT
